Toote nimi
Switch Standard 8 PoE, SFP (Gen1)
Garantii
?
24 kuu
Tootja osa number
US-8-150W
EAN
0810354024467
Switch Standard 8 PoE, SFP (Gen1)
Selle üksuse tootmine on lõpetatud
Soovitame kasutada allpool esitatud toodet
Saadaolevad alternatiivid
Detailne kirjeldus
Võrdle sarnaste toodetega
| Ethernet Pordid | ||||||
| 8 x 1 Gbps | 16 x 1 Gbps | 24 x 1 Gbps | 24 x 1 Gbps | 48 x 1 Gbps | 48 x 1 Gbps | |
| PoE välja standardid | ||||||
| 8 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 16 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 24 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 48 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | |||
| SFP pordid | ||||||
| 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP, 2 x 10G SFP+ | |
| Juhtimine | ||||||
| Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | |
| Max. energiatarve | ||||||
| 150 W | 150 W | 25 W | 250 W | 56 W | 500 W | |
| Töötemperatuur | ||||||
| -5 °C to 45 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | |
| Mõõde | ||||||
| 235 x 43 x 204 mm | 443 x 43 x 221 mm | 443 x 43 x 221 mm | 485 x 43.7 x 285.4 mm | 443 x 43 x 286 mm | 485 x 43.7 x 374.6 mm | |
| Kaal | ||||||
| 1.65 kg | 2.89 kg | 2.6 kg | 4.7 kg | 3.65 kg | 6.1 kg | |
| Paigaldamise meetod | ||||||
| Seinakinnitus, Lauaplaat | RackMount, Seinakinnitus | RackMount | RackMount | RackMount | RackMount | |
| Ethernet Pordid | 8 x 1 Gbps | 16 x 1 Gbps | 24 x 1 Gbps | 24 x 1 Gbps | 48 x 1 Gbps | 48 x 1 Gbps |
| PoE välja standardid | 8 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 16 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 24 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | 48 x Passive PoE, 802.3af (PoE), 802.3at (PoE+) | ||
| SFP pordid | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP | 2 x 1G SFP, 2 x 10G SFP+ | 2 x 1G SFP, 2 x 10G SFP+ |
| Juhtimine | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet | Ethernet |
| Max. energiatarve | 150 W | 150 W | 25 W | 250 W | 56 W | 500 W |
| Töötemperatuur | -5 °C to 45 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C | -5 °C to 40 °C |
| Mõõde | 235 x 43 x 204 mm | 443 x 43 x 221 mm | 443 x 43 x 221 mm | 485 x 43.7 x 285.4 mm | 443 x 43 x 286 mm | 485 x 43.7 x 374.6 mm |
| Kaal | 1.65 kg | 2.89 kg | 2.6 kg | 4.7 kg | 3.65 kg | 6.1 kg |
| Paigaldamise meetod | Seinakinnitus, Lauaplaat | RackMount, Seinakinnitus | RackMount | RackMount | RackMount | RackMount |
Ühilduvad tooted
Spetsifikatsioonid
Liidesed
RJ45 pordid
(8) 1 Gbps
PoE sadamate arv
8 tk
PoE välja standardid
Passiivne PoE, 802.3af (PoE), 802.3at (PoE+)
SFP pordid
(2) 1G SFP
Juhtimine
Ethernet
Võim
Toide
Sisemine PSU
Toetatud sisendpinge
100 - 240 V AC
Max. energiatarve
150 W
Füüsikalised Parameetrid
Värv
Must
Mõõde
235 x 43 x 204 mm
Kaal
1.65 kg
Töötemperatuur
-5 °C kuni 45 °C
Keskkond
Sise
Paigaldamise meetod
Seinakinnitus, Lauaplaat
Kujutegur
Töölaud
