Alfa HaLow Raspberry Pi HAT moodul
laos
?
75.62 €
75.62 €
Detailne kirjeldus
AHPI7292S on maailma esimene Wi-Fi HaLow™ Raspberry Pi™ HAT-moodul
AHPI7292S-moodulite seeria võimaldab ehitada pika ulatusega, ülimaadala võimsusega Wi-Fi-võrke alla 1 GHz litsentsivabades sagedusalades, kasutades väga populaarseid ja avatud platvorme – Raspberry Pi™. Wi-Fi HaLow™ võimaldab ühenduvust paljude rakenduste jaoks, sealhulgas andurite ja kantavate seadmete jaoks. See moodul kasutab 866 MHz sagedust, mis vastab täielikult Euroopa regulatiivsetele nõuetele.
Tänu iseseisva ja host-põhise režiimi toele, kuni 15 Mbps andmeedastuskiirusele ja täielikule SDK-le on selle uue Wi-Fi standardiga alustamine lihtne.
Omadused:
- Newracom™ NRC7292 WiFi HaLow™ SoC (vastab IEEE 802.11ah draft 8.0 standardile)
- Sagedus: 866 MHz (EL)
- Qorvo™ RFFM6901 esiosa
- DIP-lüliti režiimi valikuks ja pistik UART-i jaoks
- Raspberry Pi™ HAT vormfaktor 40-pin GPIO pistikuga
- 3× LED-i
Tehnilised andmed
Spetsifikatsioonid
Raadiovõrk
Standard
802.11ah
Pistik
RF pistikud
(1) U.FL
Süsteemi Spetsifikatsioon
Kiibikomplekti
Newracom™ NRC7292
Füüsikalised Parameetrid
Mõõde
65 × 56 × 10.3 mm
Kujutegur
Varjatud
Pakend Sisaldab
Väline toiteallikas
Ei kuulu komplekti
